High Accuracy Rotary Table Vertical Injection Moulding Machine For Customs Locks

Name: High Accuracy Rotary Table Vertical Injection Moulding Machine For Customs Locks
Brand: Lichuang Machinery
Price: 37 USD

Buy cheap High Accuracy Rotary Table Vertical Injection Moulding Machine For Customs Locks product

MOQ : 1

Delivery Time : 45-60 days

Automatic : Yes,semi-auto

Certification : CE

Voltage : 380V,50/60hz or customized,415v,3 phase,220v

Packaging Details : plywood

Plastic type : Thermoplastic

Price : 37K-67K USD

Style : Vertical,Horizontal

Screw diameter : 25mm-35mm,32 mm,28-36mm,22mm,22-25mm

Warranty : 1 Year,1 year for vertical plastic small injection moulding machine,365 DAYS,One year,2 years

Keyword : plastic injection machine,Injection moulding Machine 120tons

Model Number : V35R2/V55R2/V85R2/V120R2/V160R2/V200R2/V250R2/V320R2

After-sales service provided : Engineers available to service machinery overseas,Free spare parts,Online support,Video technical support,Overseas third-party support available

Color : White/blue,Blue,one color,Green and yellow,Customrized

Payment Terms : T/T

Type : Preform Injection,Tube Head Injection,Injection Blow Molding,screw injection,Tube Shoulder Injection

Clamping force : 15T,1200KW,150ton,3200,45 Ton

Machine weight : 35T,55T,85T,120T,160T,200T,250T,320T

Supply Ability : 5set/month

Opening stroke : 200mm,360mm,190mm,120,Can be adjust

Injection weight : 101g-6280g,1349,50~60g,39-130g,30-500g

Brand Name : Lichuang Machinery

Condition : New

Injection pressure : 1715kg/cm2 -1098kg/cm2,186-170-148,2321-1404kgf*m3,1171/996/820 kg/cm2,1475 Mpa

Power(w) : 7.5KW,4.2KW,6kw,11kw,25 KW

Place of Origin : China

Injection rate : 58cc/s,62g/s~1175g/s,80,337-368-422,20cm3/sec-30cm3/sec

Contact Now

Rotary Vertical Injection Molding Machine for Customs Locks

This turntable rotary vertical injection molding machine is customized for manufacturing TSA customs lock components. Featuring a multi-station rotary platform, it enables sequential operations of feeding, injection molding and ejection simultaneously, realizing uninterrupted cyclic production.

Stable and balanced clamping force avoids material flash on small precision lock parts. Accurate control of injection parameters ensures consistent dimensional tolerance, delivering durable lock housings with smooth surfaces and precise assembly matching.

The multi-station design greatly boosts production efficiency. It supports robotic automatic demolding to reduce manual operation. Built with sturdy frame, energy-saving hydraulic system and low failure rate, the machine shortens molding cycles, raises daily output and lowers overall production costs for luggage hardware manufacturers.

Product Gallery

High Accuracy Rotary Table Vertical Injection Moulding Machine For Customs Locks
